Technical parameters - CHASSIS
Basic frame
Steel welded from closed profiles
Permissible / operational weight
3 500 kg / 750 kg
Carrying capacity
2 750 kg at 14 MPa
Axle / number of persons
Fixed BPW / 1
Overall length / width / height
4 673mm / 1 704 mm / 1 888 mm
Brakes
On-road with automatic reverse
Towing eye: height from the ground / diameter-fixed
500 mm / 40 mm
Drawbar load max. load / max. drawbar load when stretching
↓ 500 kg / ↑ 500 kg pro 2 800 kg
Drawbar support
Retractable wheel
Tires
10.00/75 - 15.3 diagonal
Technical parameters - CONTAINER CARRIER
Carrier construction
Steel welded from closed profiles
Container length min / max
3 200mm - 3 400 mm
Drive and control
1 x tractor hydraulics circuit, mechanical switching between extending and folding
Volume of oil required for aggregation
5 L
Max. carrier performance
1 500 kg / 8 MPa - 2 900 kg/ 14 MPa
Securing the container
Passive
Tilting of the container when extending / folding
33º / 53º
Hydraulic oil
Viscosity index 98, according to DIN ISO 2909
Complete specifications and price on request
